Industrial Water Meter
WS-F is designed to measure the total volume of unidirectional water passing through large pipeline in sizes of 50mm to 200mm, such as tap water, well water, river water, as well as sewage, except corrosive water.
Features
* It is a vertical woltman water meter.
* Mechanical transmission movement equates to maximum reliability.
*The chamber of the rollers is liquid filled sealed for protecting the inner parts from the moisture and dust penetrat ion.
* Sealed wet dial register.
* Removable structure, easy maintenance.
* The measuring mechanism can be removable from the body for checking, maintaining and replacing, and the body needn't be dismantled from the pipeline.
* Inter-exchangeable parts.
* Low pressure loss.
* Particularly suited in lower quality water.
* Can be equipped with reed switch (register can't rotate).
Standard Compliance
Technical data conforms to ISO 4064
Class C, R160 and R200 standard.
Working Conditions
Water temperature: ≤50ºC for cold water meter
Water pressure: ≤1MPa or 1.6MPa or 4.0 MPa optional (10bar or 16bar r 40 bar optional)
Installation requirements
*Pipeline must be flushed before installation.
*The meter should be constantly full of water during operation.
Maximum Permissible Error
In the lower zone from Qmin(Q1) inclusive up to but excluding Qt (Q2) is ±5%.
In the upper zone from Qt(Q2) inclusive up to and including Qmax(Q4) is ±2%(cold water meter).
MAIN TECHNICAL DATA According to ISO4064 :2003 (Old Standard)
| Meter Size | Measuring | Max Flow | Nominal Flow | Transitional Flow | Min Flow | Min Reading | Max Reading | |
| mm | class | m³/h | m³ | |||||
| 50 | C | 30 | 15 | 22.5 | 90 | 0.0005 | 999999 | |
| 80 | C | 80 | 40 | 60 | 240 | 0.0005 | 999999 | |
| 100 | C | 120 | 60 | 90 | 360 | 0.0005 | 999999 | |
| 150 | C | 300 | 150 | 225 | 900 | 0.005 | 9999999 | |
| 200 | C | 500 | 250 | 375 | 1500 | 0.005 | 9999999 | |
MAIN TECHNICAL DATA According to ISO4064:2005 (New Standard)
| Meter Size | Measuring | Q4 | Q3 | Q2 | Q1 | Min Reading | Max Reading |
| mm | R | m³/h | m³ | ||||
| 50 | 160 | 50 | 40 | 400 | 250 | 0.0005 | 999999 |
| 200 | 320 | 200 | |||||
| 80 | 160 | 78.7 | 63 | 630 | 393.75 | 0.0005 | 999999 |
| 200 | 504 | 315 | |||||
| 100 | 160 | 125 | 100 | 1000 | 625 | 0.0005 | 999999 |
| 200 | 800 | 500 | |||||
| 150 | 160 | 312.5 | 250 | 2500 | 1562.5 | 0.005 | 9999999 |
| 200 | 2000 | 1250 | |||||
| 200 | 160 | 500 | 400 | 4000 | 2500 | 0.005 | 9999999 |
| 200 | 3200 | 2000 |
Dimensions and Weight
| Meter size | Length L | Width W | Height H | Connecting thread | ||
| mm | mm | D | Bolt circle Dia D1 | Conncting bolt | ||
| 50 | 280 | 245 | 300 | 165 | 125 | 4xM16 |
| 80 | 370/225 | 280 | 300 | 200 | 160 | 8xM16 |
| 100 | 370/250 | 300 | 345 | 220 | 180 | 8xM16 |
| 150 | 500 | 335 | 445 | 285 | 240 | 8xM20 |
| 200 | 550 | 386 | 476 | 340 | 295 | 8xM20 |
